Automatic CNC Fabric Leather Cutter Digital Cutting Machine
$7,645.46
Subscription successful
You’re now subscribed to price tracking for this product. We’ll notify you if the price drops.
Fast Delivery
Quick, reliable shipping to any location.
Free & easy returns
Return this item by mail or in store within 90 days for a full refund.
Description
Description
Product Paramenters
Model | RT-D2516/RT-S2516 |
working area | 1600*2500MM |
Machine size | 3450×2300×1250MM |
Rated power | 9kw |
Fixed model | Flated working table |
Multifunctional head | Swiss imported knife: with vibration full cutting. vibration half cutting and cursor location function. |
Safety device | Using infrared sensors. responsive. safe and reliable. |
translational velocity | 800-1200mm/s |
Cutting thickness | 200-800mm/s(according to different cutting materials) |
Cutting materials | Leather. all kinds of clothing flexible material. Sponge composite leather. PVC. soft glass. Silicon. rubber |
Repeated accuracy | ≤0.1mm |
Transmission system | imported(Digital servo motor. linear guide. synchronous belt. ball screw) |
Instruction system | HP-GL compatible format |
Voltage | 380V±10% |
Other configuration | Japanese Yaskawa servo motor.Germany imported conveyor belt. vacuum table. auto feeding. Taiwan Hiwin rail. 7.5kw vacuum pump |
Details Images
Product Applications
Company Profile
REALTOP CNC is a well-known CNC equipment manufacturer with more than 15 years machine production experience. We created "REALTOP" brand. and mainly engaged in the research and development. production. marketing and services of Oscillating Knife Digital Cutting Machine which is widely used for cutting soft materials. such as cardboard. corrugated paper. paper honeycomb.leather. glass fiber. carbon fiber. fabric. sticker. film. foam board. acrylic board. rubber. gasket material. garment cloth. footwear material. bags materials. non-woven fabrics. carpets. sponge. PU. EVA. XPE. PVC. PP. PE. PTFE. ETFE and composites.
Company successfully produce Realtop series products of more than 50 sorts. which enjoy good reputation and support. Excellent quality and fast service makes our products spread all over the world. such as Europe. Middle east. America. and South Asian. etc.
As for the terms of trade. we support FOB.CIF.EXW.CFR.etc. As for your requirements.
Why Choose Us
Our Advantage
1. The machine is equipment with vibrating knife cutting technology. which saves the cost and time of manufacturing. management and storage of cutter. Farewell completely to the traditional manual cutting technology. completely break through the bottleneck of enterprises dependence on skilled workers. and take the lead in the era of digital tool-free die processing.
2. Multifunctional cutting head design. highly integrated multi-group processing tools. can be in a unit of work for interactive cutting. punching. marking. to achieve a one-stop operation.3. Powerful layout and calculation system can achieve automatic layout and accurate calculation. thus accurately calculating costs. accurately controlling material distribution. and truly realizing the digital zero inventory strategy.4. By accurately simulating each operation process by computer. the programmed operation is realized. which eliminates the interference of personal factors such as worker's emotion. technology and fatigue. avoids the hidden waste and improves the material utilization rate.
5. Timely modification of the template can be achieved. saving the time of developing and laying out the board. quickly changing the board. and adapting to the fast and changeable market demand. The same board adjustment can lead your competitors by 2-3 days and help you seize the market opportunity quickly.
FAQ
Q1: How to get the most suitable machine and best price
Please tell us: 1.the material you wanna handle 2.the Max size of these materials(length.width and thickness) 3.the work you wanna handle with this machine(Engraving ?Cutting ?Or others?)
Q2: Do you have the manual of machine.
Yes.we can provide manual.CD software and video to help you operate the machine expertly.
Q3: If we do not know how to use the machine.can you teach us?
Yes .of course. We can offer you free training. and engineers available to service machinery training overseas if you would like to offer them business expenditure.
Q4.How about your guarantee period?
12 months for whole machine.
Q5:Can I customize the machine to meet my requirements?
Yes. we support OEM&ODM.If you want to customize the machine. please contact our customer service staff and inform us of your requirements
Q6: How long can I receive the machine?
Normally. we will deliver the goods in 7-10 working days. Depending on the route. it takes about 20-35 days in European and American countries. In Southeast Asian countries. it takes about 10-30 days.Of course. the time is for reference only. if you want more accurate time information. please contact us
Additional information
Additional information
| model number |
D1216 ,D2520 ,DD2516 |
|---|---|
| working area |
1200*1600mm ,2500mm*1600mm ,2500mm*2000mm |
Product Paramenters
Model | RT-D2516/RT-S2516 |
working area | 1600*2500MM |
Machine size | 3450×2300×1250MM |
Rated power | 9kw |
Fixed model | Flated working table |
Multifunctional head | Swiss imported knife: with vibration full cutting. vibration half cutting and cursor location function. |
Safety device | Using infrared sensors. responsive. safe and reliable. |
translational velocity | 800-1200mm/s |
Cutting thickness | 200-800mm/s(according to different cutting materials) |
Cutting materials | Leather. all kinds of clothing flexible material. Sponge composite leather. PVC. soft glass. Silicon. rubber |
Repeated accuracy | ≤0.1mm |
Transmission system | imported(Digital servo motor. linear guide. synchronous belt. ball screw) |
Instruction system | HP-GL compatible format |
Voltage | 380V±10% |
Other configuration | Japanese Yaskawa servo motor.Germany imported conveyor belt. vacuum table. auto feeding. Taiwan Hiwin rail. 7.5kw vacuum pump |
Details Images
Product Applications
Company Profile
REALTOP CNC is a well-known CNC equipment manufacturer with more than 15 years machine production experience. We created "REALTOP" brand. and mainly engaged in the research and development. production. marketing and services of Oscillating Knife Digital Cutting Machine which is widely used for cutting soft materials. such as cardboard. corrugated paper. paper honeycomb.leather. glass fiber. carbon fiber. fabric. sticker. film. foam board. acrylic board. rubber. gasket material. garment cloth. footwear material. bags materials. non-woven fabrics. carpets. sponge. PU. EVA. XPE. PVC. PP. PE. PTFE. ETFE and composites.
Company successfully produce Realtop series products of more than 50 sorts. which enjoy good reputation and support. Excellent quality and fast service makes our products spread all over the world. such as Europe. Middle east. America. and South Asian. etc.
As for the terms of trade. we support FOB.CIF.EXW.CFR.etc. As for your requirements.
Why Choose Us
Our Advantage
1. The machine is equipment with vibrating knife cutting technology. which saves the cost and time of manufacturing. management and storage of cutter. Farewell completely to the traditional manual cutting technology. completely break through the bottleneck of enterprises dependence on skilled workers. and take the lead in the era of digital tool-free die processing.
2. Multifunctional cutting head design. highly integrated multi-group processing tools. can be in a unit of work for interactive cutting. punching. marking. to achieve a one-stop operation.3. Powerful layout and calculation system can achieve automatic layout and accurate calculation. thus accurately calculating costs. accurately controlling material distribution. and truly realizing the digital zero inventory strategy.4. By accurately simulating each operation process by computer. the programmed operation is realized. which eliminates the interference of personal factors such as worker's emotion. technology and fatigue. avoids the hidden waste and improves the material utilization rate.
5. Timely modification of the template can be achieved. saving the time of developing and laying out the board. quickly changing the board. and adapting to the fast and changeable market demand. The same board adjustment can lead your competitors by 2-3 days and help you seize the market opportunity quickly.
FAQ
Q1: How to get the most suitable machine and best price
Please tell us: 1.the material you wanna handle 2.the Max size of these materials(length.width and thickness) 3.the work you wanna handle with this machine(Engraving ?Cutting ?Or others?)
Q2: Do you have the manual of machine.
Yes.we can provide manual.CD software and video to help you operate the machine expertly.
Q3: If we do not know how to use the machine.can you teach us?
Yes .of course. We can offer you free training. and engineers available to service machinery training overseas if you would like to offer them business expenditure.
Q4.How about your guarantee period?
12 months for whole machine.
Q5:Can I customize the machine to meet my requirements?
Yes. we support OEM&ODM.If you want to customize the machine. please contact our customer service staff and inform us of your requirements
Q6: How long can I receive the machine?
Normally. we will deliver the goods in 7-10 working days. Depending on the route. it takes about 20-35 days in European and American countries. In Southeast Asian countries. it takes about 10-30 days.Of course. the time is for reference only. if you want more accurate time information. please contact us
